Description
Hexing 3-Phase Split Prepaid Electricity Submeter
Securely manage heavy power demands and streamline utility cost recovery with the Hexing Three Phase Split Prepaid Electricity Submeter. Specifically designed for commercial buildings, industrial facilities, and larger residential properties operating on a 3-phase electrical supply, this submeter offers the perfect combination of maximum security and end-user convenience.
Its split configuration houses the primary metering unit safely inside a main distribution board, panel, or lockable enclosure, while the separate Customer Interface Unit (CIU) keypad is placed conveniently inside the tenant’s workspace or living area. This isolation protects the main measuring unit from unauthorized access and physical tampering while making token entry effortless for the user.
Ideal Applications
The Hexing 3-Phase Split Submeter is the ideal choice for private utility management across high-demand properties, including:
- Commercial properties, office parks, and shopping centres
- Industrial units, factories, warehouses, and workshops
- Multi-tenanted commercial developments with shared distribution boards
- Residential estates, complexes, and large multi-unit homes with 3-phase power
- High-demand submetering installations where tamper protection is critical
Key Features & Benefits
Maximum Tamper Protection & Security
By locking the main 3-phase meter unit securely inside a distribution board or sub-panel, property owners drastically reduce the risks of illegal bypass, physical tampering, and unmetered power consumption.
Separate Customer Interface Unit (CIU)
Tenants easily recharge their electricity using a dedicated indoor keypad unit (CIU). Tokens are keyed directly into the CIU via a standard 20-digit STS keypad without requiring access to the main distribution board.
STS Compliant & High-Demand Load Handling
Fully compliant with the Standard Transfer Specification (STS), accepting 20-digit encrypted tokens engineered to handle heavy commercial and industrial three-phase electrical loads.
Accurate 3-Phase Consumption Tracking
Replaces dispute-prone estimated billing and complex shared accounts with precise, real-time energy measurement dedicated to each specific tenant or zone.
Seamless Enbaya Vending Integration
Pre-configured to work directly with Enbaya’s 24/7 vending platform, allowing tenants to purchase prepaid top-up tokens anytime via online banking, mobile apps, or supported retail outlets.
How the 3-Phase Split Submeter System Works
- Secure Panel Installation: The main 3-phase submeter unit is mounted inside the primary distribution board or locked panel, downstream of the municipal or utility meter.
- CIU Placement: The separate Customer Interface Unit (CIU) keypad is installed in an easily accessible location inside the tenant’s unit or office.
- Token Purchase: The tenant purchases prepaid electricity tokens through Enbaya’s vending channels and receives a standard 20-digit STS code.
- Remote Keypad Entry: The tenant keys the 20-digit token into the indoor CIU keypad. The credit transfers to the main meter unit, instantly updating the available kilowatt-hour (kWh) balance.
Technical Specifications
- Brand: Hexing
- Model: HXE330 (Split Configuration)
- Product Type: Prepaid electricity submeter
- Phase: Three phase
- Configuration: Split type (Main meter + separate indoor CIU keypad)
- Customer Interface: Separate CIU keypad (20-digit STS entry)
- Token Standard: STS compliant
- Application: Commercial, industrial, and large residential 3-phase submetering
Is This 3-Phase Split Submeter Right for You?
Choose the Hexing Three Phase Split Prepaid Submeter if your property has a 3-phase supply and you want to keep the main meter safely locked away in a distribution panel while giving tenants a convenient indoor keypad for token top-ups.
Note: If the submeter can be mounted in an accessible area where tenants can enter tokens directly on the front display, a Three Phase Integrated Prepaid Submeter may be used. For standard domestic single-phase connections, select a single-phase submeter instead.
Important Notice: This device is a secondary submeter intended for private 3-phase consumption management and utility cost recovery downstream of the main supply. Installation must be performed by a qualified electrician in compliance with applicable local electrical regulations.
Why Choose Enbaya Prepaid Meters?
Backed by 23 years of specialized experience in prepaid submetering solutions, Enbaya provides complete utility management supported by proven technology and dedicated operational service:
- 23 years of industry leadership in prepaid submetering
- Reliable 24/7 prepaid token vending platform for tenants
- Dedicated technical support and customer care helplines
- Hassle-free meter registration and landlord revenue collection
- Free site inspections available for qualifying commercial projects
Take control of your 3-phase utility recovery today.
Order your Hexing Three Phase Split Prepaid Submeter online now or explore our full range of Enbaya Prepaid Submeters.
IMPORTANT:Â This meter is managed by the Enbaya Prepaid Management System.
